A datatype element is used to define additional datatypes which are not available in the default set of provided datatypes. They can be modified in the datatype editor.

Standard (Predefined) Types

A number of types are already built into and well-known to expecco. These are:

Common Types

• Address

represents a pointer to external data (C-pointer)

• Any

any object, exact type is not known/not relevant

• BitString

an array of bits

• Boolean

boolean truth values: true and false

• ByteArray

a collection of bytes

• Collection

a collection of any other object (possibly unordered)

• Date

represents a date (dd-mm-yy)

• DateTime

represents both date and time (aka: timestamp) with millisecond resolution

• Dictionary (HashTable)

a mapped collection, where the key/index may be any arbitrary object

• Filename

represents a path/file name

• Float

a rational number with double-precision (64bit)

• Fraction

an exact fraction

• Handle

a handle as returned by some operating-system calls

• HexString

• IPAddress

• Integer

an arbitrarysize integer

• Number

any numeric value (integer, float or fraction)

• OctedString

• OrderedCollection

a growable collection, with integral index

• SequenceableCollection

any collection, with integral index (possibly non-growing)

• Set

an unordered collection, where every object occurrs at most once

• Socket

represents a socket connection stream

• Stream

any stream

• String

a collection of 8-bit characters

• StringCollection

a collection of lines, as read from a file

• StringOrFilename

a union either a fileName object, or a string

• Time

represents the time of the day (hh:mm:ss)

• TimeDuration

represents a time-delta (10m, 1h or 3d)

• URL

• UUID

• UnicodeString

Expecco Types

• ActivityLog
• Datatype
• Error
• Exception
• GUI Aspect
• Library
• Performer
• Report Template
• Resource
• SUnit TestResult
• Symbol
• Verdict

User Defined Types

New user defined types can be constructed by a number of different mechanisms:

Primary Types

Primary types represent existing classes of the underlying VM (virtual machine). These are the classes as described in the Smalltalk/X Online Documentation in addition to any classes which have been loaded dynamically via the plugin mechanism.

Compound Types

A compound type consists of a number of named fields, each defined by its type. For example, a customer record could be represented by a compound type instance as a structure consisting of individual fields:

compound type:

    {
        firstName: String
        lastName: String
        zip: Integer
        age: Integer
    }

when instantiated, an anonymous class is created for instances of compound types. These objects provide virtual accessor functions (getters and setters), which are named as the field names. Thus, given a compound type T, it can be instanciated with:

    inst = T.new();

and the fields can be set with:

    inst.firstName( "Andy" );
    inst.lastName( "Miller" );
    inst.age ( 41 );

Enumeration Types

An instance of an enumerated type can take a valuefrom a defined list of values. For example, a test-outcome could be defined as an enumerated type:

enum type:

    (
        pass | fail | inconclusive
    }

(notice, that there is already a Verdict type present in the set of standard types).

Subrange Types

A subrange of the set of values of either the integer- or the character type. A subrange type defines the minimum and maximum values from the base type's set of values.

For example, a type to describe byte-valued integers could be described as:

range( Integer : 0 .. 255 )

Union Types

A union type represents a number of alternative fields. The selection of which field is actually valid within a union must be done elsewhere (or, via reflection, by asking the object dynamically).

For example, a type to describe an object which is either numeric or a string, could be described as:

union type:

    (
        String | Integer
    )

CTypes (1.7.4)

A cType is similar to a compound type; however, a data representation is used, which is compatible to structures of the C-programming language. Also, the definition is given in C-syntax. For example, the above customer record could be represented as the following C-structure:

cType type:

    /* C: */
    struct {
        char firstName[20];
        char lastName[20];
        int zip;
        short age;
    }

Notice the explicit dimension of the strings. These are required to define the C-structures exact size. When instantiated, an object is created, which has the underlying C-structure layout, and which is not moved in memory by the garbage collector (i.e. its address remains constant). It can therefore be passed to a called c-functions, for example in a dll call. Similar to compound types, isntnaces of cTypes understand accessor functions. Given a ctype type T, it can be instanciated with:

    inst = T.new();

and the fields can be set with:

    inst.firstName( "Andy" );
    inst.lastName( "Miller" );
    inst.age ( 41 );

Notice that cTypes are not supported by expecco releases before 1.7.4. Also notice, that C-structures are allocated using malloc on the C-heap. The overhead in terms of memory use and processing power is therefore much higher when compared to normal compound- or primary instances. Only use cType instances when data has to be exchanged with C-programs.

Special Types
